If you work on roads in Ontario – towing, plowing, paving, line painting, traffic control or utility work – you’ve probably heard people talk about “Book 7”.

This guide explains, in plain language, what Ontario Traffic Manual Book 7 – Temporary Conditions says about vehicle warning lights, and how that affects the way you kit out your trucks.

Note: This is a summary for general understanding. For detailed requirements, always refer to the current edition of Book 7 and any Ministry of Labor, Immigration, Training and Skills Development, MTO or employer policies.

What Book 7 Is (and What It Isn’t)

Book 7 is part of the Ontario Traffic Manual (OTM). It provides standard practices for temporary traffic control – things like lane closures, flagging operations, mobile work and work zones.

Key points:

It is aimed at transportation practitioners and work zone planners, not just individual drivers.
It lays out typical setups, signs, devices and vehicle requirements for different types of work.
It does not act as a full Highway Traffic Act by itself, but it is widely used by inspectors and safety professionals when assessing work zones.

Book 7 and Work Vehicle Lighting

In the context of work vehicles used in temporary traffic control, Book 7 consistently references:

Four-way hazard flashers, and
A 360° amber beacon or rotating/flashing amber light on certain vehicles in the work zone.

For example, in many of the layout diagrams for lane closures and mobile operations, Book 7 shows:

A sign truck or work vehicle with
- 4-way flashers activated, and
- A 360° amber beacon in operation.

In practice, that means:

If your vehicle is part of an active Book 7 work zone, it is generally expected to display hazard flashers and a 360° amber warning light that is visible from all directions when required by the layout.

Excerpt from Book 7:

4.5.1.3 (page 211)

To enhance visibility of BV and work vehicles, lightings are installed on vehicles to support field
operations. Especially during situations with limited visibility, such as storm events and nighttime,
appropriate vehicle lightings help to mitigate traffic hazards to workers and drivers on public
highways. Vehicles that require lightings to function as a traffic control device are typically equipped
with either four-way flashers (4WF) plus 360-degree beacon, rotating LED amber lights, or TC-12.

A 360-degree beacon is a device with an amber light source that continually shows the light source
through all 360 degrees of the compass, completing a full rotation every 1.5 seconds. If a 360-degree
beacon is used, the four-way flashers are not required to be operated continuously for longer duration
work.

Alternatively, rotating LED amber lights can be used in place of 4WF plus 360-degree beacon.
The rotating LED amber lights must be positioned as a pair; one on the left and the other on the
right, mounted and installed at a height so visible from 360 degrees around. Listed below are the
specifications required of rotating LED amber lights:

a) SAE J845 Compliant. SAE J845 provides design guidelines, test procedure references,
and performance requirements of optical warning devices for authorized emergency,
maintenance, and service vehicles.

b) Cover can be either amber or clear.

c) Rotational light pattern in 0.8 to 1.2 Hz range (no strobes or flashes) and both lights
shall be in sync with each other having the Identical pattern.

d) Full 360-degree LED light output and must not be able to do any other pattern.

e) Output of 2500-3000 lumens in non-dimmed state

f) Auto-dim at night or have switch in cab to enable dim function

g) “ON/OFF” switch in cab shall be lighted when Rotating LED Amber Lights are in
operation

Colours: Book 7 and Amber

Book 7 focuses on amber as the standard warning colour for work vehicles in temporary traffic control setups. It does not go into detailed discussion of green, red or blue – those colours are dealt with under the Highway Traffic Act and related regulations.

So for Book 7 purposes:

Think amber = traffic control and work zone visibility.
Additional scene lights (often white) may be used for illumination, provided they don’t blind road users or create confusion.

Practical Considerations for Fleets

If your vehicles regularly appear in Book 7-type setups (lane closures, shoulder work, mobile work):

Equip them with a reliable, SAE-compliant amber beacon or light bar that provides 360° visibility.
Ensure hazard flashers are functional and can be run simultaneously with the beacon.
For larger fleets, consider standardizing beacon locations and switch labelling so operators know exactly what to activate when entering a work zone.
Train staff on when lighting is required or recommended according to your Book 7 layouts and internal safety policies.
